4 Step Control Weighing Indicator
FS-8000AC Model will be used for 2STEP CONTROL(HIGH, LOW), INPUT WEIGHING,
DISCHARGING WEIGHING, ACCUMULATING WEIGHING in Industrial Factory
Which can control the correct material weight and totalized weight data.
Features
● Compact Appearance by DIN regulations ( DIN 186 x 92 Panel Insertion )
● RS-232C Serial Interface & Current Loop Interface is the standard function
● Set up to Max. 1/30,000 display resolution
● Function available to change the unit value such as kg, ton, lb, g
( In case of Serial Interface & Printer )
● It can track the based zero value without adjusting the DIP-Switch in Calibration
● Selectable A/D Conversion Speed(25,30,50,60,100,150,180,200,240 Times/Sec)
(SET UP F94)
● Available to use the same load cell Until Max. 16pcs ( 300Ω standard )
● Easy to set up, change, check several values by the numeral key.
● Improved a convenience and precision of operating by Message Function.
● It can display a various information by F1, F2, F3 key for the end-user.
● Watch-Dog Guards for self-diagnostics.
● Various option Functions for the end-user `s satisfaction such as RS-422/485,
● Current Loop, Analog out, BCD Input / Output and so on.
● Available to print by either Serial Interface or Centronics Parallel Interface
Specification
1. Analog Input & A/D Conversion
Input Sensitivity
| 0.2 ㎶/D
|
Load cell excitation
| DC 5V
|
Max. Load cell Input
| 1mV/V∼5mV/V
|
Temperature Coefficient
| ± 5 ppm / ℃
|
INPUT Noise
| ± 0.5 ㎶ P.P
|
INPUT Impedance
| More than 10 ㏁
|
A/D Converter
| 520,000 Count
|
A/D Conversion Speed
| 25, 30, 50, 60, 100, 120, 150, 180, 200, 240회/초 (Select)
|
Non-Linearity
| 0.003％ F.S
|
2. DIGITAL
MAX.DISPLAY
| "999999"
|
MIN.DIVISION
| x1, x2, x5, x10, x20, x50
|
DISPLAY UNIT
| 7-Segment, 6digit Highly bright fluorescent(LED Type)
|
KEY BOARD
| Numerical Key and Function Key(0-9,CLR,SET/CLR)
|
Data Back-up
| More than 20Years
|
3 . GENERAL
POWER
| AC10 / 24V (±10%), Free Voltage 50 / 60Hz, 10VA
|
PRODUCT WEIGHT
| NET 1.2kg BOX 2.0kg
|
Operating Temperature
| -10℃ ∼ 40℃
|
Operating Humidity
| 85%RH MAX (Non-Condensing)
|
External Dimension
| 198 x 99 x 101mm, Install Size 186 x 92mm
|
4. OPTION
OP-03
| Parallel I/F : BCD Out Weight
|
OP-04
| Serial I/F : RS422, RS485
|
OP-05
| Analog Voltage Out (0-5V / 0-10V)
|
OP-06
| Analog Current Out (4-20mA)
|
OP-07 | Print I/F : CENTRONICS Parallel
|
OP-10
| Parallel I/F : BCD In PART
|
OP-11
| Serial I/F : CH-A, CH-B Extension
CH-A = RS-232C, Current Loop
CH-B = RS-232C, RS422, RS485
|
Cutting Size
